— Hydraulic Cylinder
| Name | Model | Rated Pressure (MPa) | Cylinder Bore Diameter (D) | Rod Diameter (d) | Stroke (S) | Installation Distance (L) |
|---|---|---|---|---|---|---|
| Hydraulic Cylinder for Rolling Mill Rolls | 380/340-475 | 16 | 380 | 340 | 475 | 2190 |
| Stepping Hydraulic Cylinder | 280/200-800 | 25 | 280 | 200 | 800 | 2345 |
| Straightening Hydraulic Cylinder | 200/140-250 | 16 | 200 | 140 | 250 | 270 |
| Straightening Hydraulic Cylinder | 160/100-140 | 16 | 200 | 100 | 140 | 632 |
| Push - Pull Hydraulic Cylinder | 160/90-3200 | 16 | 160 | 90 | 3200 | 150 |
| Lifting Hydraulic Cylinder | 140/100-850 | 16 | 140 | 100 | 850 | 1535 |
| Lifting Hydraulic Cylinder | 125/90-550 | 16 | 125 | 90 | 550 | 460 |
| Boom Hydraulic Cylinder | 150/90-1120 | 16 | 150 | 90 | 1120 | 1700 |
| Relieving Hydraulic Cylinder | 125/70-850 | 16 | 125 | 70 | 850 | 75 |
| Relieving Hydraulic Cylinder | 125/70-390 | 16 | 125 | 70 | 390 | 960 |
| Pressure - equalizing Valve Hydraulic Cylinder | 63/35-490 | 16 | 63 | 35 | 490 | 790 |
| Vibration Servo Hydraulic Cylinder | 80/50-25 | 20 | 80 | 50 | 25 | 330 |
| Servo Hydraulic Cylinder | 160/110-440 | 20 | 160 | 110 | 440 | 1255 |
| Double - rod Hydraulic Cylinder | 80/55-2490 | 16 | 80 | 55 | 2490 | 252 |
| Steel Ladle Nozzle Hydraulic Cylinder (High - temp Water Jacket) | 100/45-220 | 16 | 100 | 45 | 220 | 112 |
| High - temperature resistant hydraulic cylinder | 150/90-690 | 16 | 150 | 90 | 690 | 1000 |
| High-temperature resistant hydraulic cylinder (water-cooled) | 160/110-300 | 16 | 160 | 110 | 300 | 1070 |
| Tensioning Hydraulic Cylinder | 70/50-95 | 16 | 70 | 50 | 95 | 180 |
| Tensioning Hydraulic Cylinder | 90/45-100 | 16 | 90 | 45 | 100 | 260 |
| High-temperature resistant air cylinder | 250/70-150 | 0.8 | 250 | 70 | 150 | 720 |
| Clamping air cylinder | 125/35-150 | 0.8 | 125 | 35 | 150 | 507 |
| Clamping air cylinder | 100/25-100 | 0.8 | 100 | 25 | 100 | 223 |
We excel in manufacturing rubber injection molding machines,hydraulic cylinders, and custom rubber-plastic seals. Our premium products, renowned for reliability, are extensively applied in automotive and industrial fields and exported globally. OEM/ODM services are also available.
